32Pack – Lotus Lotolite SC-DL09-D04H-A1-61RE – 4″ 9W Slim Round LED High-Lumen

Lead Time: Normally Ships in 3-5 Business Days
Need it Sooner? Contact Us

Price from :
CAD$ 443.52

Lotus LED Lights introduces Lotolite 4″ Slim Round Panel High-Output LED downlight, offer you 5 different kelvin temperature options to choose from. Utilize the switch inside the integral driver that comes with each light to choose between warm 27K, warm 30K, warm-neutral 35K, neutral 40K, or daylight 50K white light color temperatures. Perfect option for contractors to stock up on, allowing you to suit each downlight to your customer’s preferences. For the end user, these are also easy to change as preferences do. The versatility of choices combined with the quality you’ve come to expect from Lotus LED Lights, the original IC-rated thin downlight manufacturer, combined with a price that won’t break your budget make these lights the best choice for you in your new construction or renovation light installations.

The SC-DL09-D04H-A1-61RE a 9 watt, 4″ Slim Round Panel High-Output LED Recessed downlight in a White or Black finish with the following features:

  • 32PCS in a PACK
  • Lotolite 4″ Slim Panel – delivering an impressive high-lumen output of 1000 lm from 9W
  • Up to 120 lm/W – Best in Class Efficiency
  • 5 CCT Field Selectable 2700-3000-3500-4000-5000K
  • Type IC, Air-Tight & Wet Location Rated – No Housing Required
  • CRI 90+ for true color rendering
  • White & Black trims in stock
  • Triac Dimmable with most CL dimmers 120V input
  • cETLus, FCC, Energy Star, JA8 certified

Product Information

CONSTRUCTION:
Round 4″ Ultra Slim Recessed fixtures with integral Driver in Connection Box.
One driver for every fixture required.

MOUNTING:
Cut Hole In Ceiling And Snap Fixture In Opening With Attached Spring Clips.
Ceiling Clearance Required for driver to fit: 2 1/2″

  • Energy Used: 9W
  • Halogen equivalent: 100W
  • Beam Angle: 110°
  • Light colour: 5 CCT Field Selectable 2700-3000-3500-4000-5000K
  • Light output: 960-980-1015-1030-1020 lm
  • CRI: 90+
  • Driver Input Voltage: 100-130 V AC
  • Dimmability – TRIAC Dimmable 10% – 100%
  • White & Black trims in stock
  • Ambient Operating Temperature: -4°F (-20°C) to +104°F (+40°C)
  • Warranty: 3 Years
  • Compliance: cETLus, FCC, Energy Star, JA8

DIMENSIONS:

  • ID 4″; OD 4 7/8″; Thickness 1/2″
  • Cut out: 4 1/4″
  • Junction Box Dimensions (with driver inside): 4 3/4″ x 2 3/4″ x 1 3/8″

Suitable for Insulated Ceilings & Wet Locations.

Specification Sheet

Installation Instructions

Photometric PDF files:
PDF at 2700K | PDF at 3000K | PDF at 3500K | PDF at 4000K | PDF at 5000K

Photometric IES files:
IES at 2700K | IES at 3000K | IES at 3500K | IES at 4000K | IES at 5000K


Link to Energy Star: SC-DL09-D04H-A1-61RE
